| Gasoline Generator Series | ||||
|---|---|---|---|---|
| Model | HHB700 | HHB1200 | HHB2000 | HHB3000 |
| Engine Model | 152F | 160F | 168F | 170F |
| Type | Single cylinder, air-cooled, 4-stroke | Single cylinder, air-cooled, 4-stroke | Single cylinder, air-cooled, 4-stroke | Single cylinder, air-cooled, 4-stroke |
| Displacement(ml) | 84.9 | 113 | 164 | 173 |
| Rated Power(kW) | 0.7 | 1.0 | 1.5 | 2.2 |
| Max. Power(kW) | 0.8 | 1.2 | 2.0 | 3.0 |
| Frequency(Hz) | 50/60 | 50/60 | 50/60 | 50/60 |
| Voltage(V) | AC 220/DC 12 | AC 220/DC 12 | AC 220/DC 12 | AC 220/DC 12 |
| Noise Level(dB) | 68-75 | 68-75 | 68-75 | 68-75 |
| Fuel Type | Gasoline 90# | Gasoline 90# | Gasoline 90# | Gasoline 90# |
| Fuel Tank Capacity(L) | 1.0 | 2.0 | 3.6 | 3.6 |
| Continuous Running Time(h) | 3-4 | 5-6 | 7-8 | 6-7 |
| Starting System | Recoil start | Recoil start | Recoil start | Recoil start |
| Lubrication Type | Splash | Splash | Splash | Splash |
| Dimension(L×W×H)(mm) | 390×290×330 | 420×320×350 | 450×360×420 | 450×360×420 |
| Net/Gross weight(Kg) | 10/11 | 12/13 | 16/17 | 18/19 |
